KS-2610 High speed metal sawing machine

Characteristic description

● Bed mechanism: one cast bed, secondary aging stress relief, high stability, high precision, good seismic performance;

● Wide sawing range, compact design, 35-735 width sawing range, unlimited length. The industry's most compact design, the most space saving;

● Feeding mechanism: a new generation of high-speed feeding design, stronger feeding rhythm, more efficient than traditional guide screw transmission, longer accuracy maintenance;

● Bridge type workbench: the working table is matched with a roller and a universal ball, which reduces the friction resistance between the material and the workbench, has higher feeding accuracy and prevents dropping;

● Intelligent operating system: easy to use between operations, highly man-machine visualization, reducing customer training time for operators;

● Raster ruler positioning: sawing can be completed for small parts and spare parts quickly, raster ruler data connection system and automatic data acquisition.

PREV：KS-7010 High Speed Cutting Board Circular Saw MachineNEXT：No next article

Product Description

Contact Form

Product model

KS-2610

Cutting capacity mm



Plate mm

1900-2600

Maximum sawing thickness mm

100

Head spindle



Spindle motor kw

30.0 Permanent magnet motor

Spindle speed

20-110

Feed method

Servo incision

Feed servo motor kw

2.9

Saw blade cleaning

Wire wheel brush

Saw blade specification mm

460×50×2.3×3.0×60T

Feeding clamp



Feeding drive method

Servo feed

Feeding servo motor kw

2.9

Feeding clamping method

Hydraulic vise clamp*4

Pressing method

Hydraulic cylinder multi-stage downpressure

Front end material head length mm

10-99(optional uncut head)

Rear end tail length mm

260

Single feed length mm

Maximum 1000 (can be multiple times)

Saw cutting accuracy



Saw length error mm

<0.2/100 (except stress deformation)

Saw verticality mm

0.2/100

Shipping accuracy mm

0.5/500

Hydraulic device and air pressure



Hydraulic oil pump motor kw

7.5

Hydraulic system pressure Mpa

7-10

Hydraulic fuel tank capacity L

150

compressed air bar

5-7

Machine tool body



Machine tool size mm

9650×6250×2150

Machine tool weight T

28

Chip conveyor way

Screw + chain chip removal
